Used Machines

Multivac R530 420mm

Manufacturer:

Multivac

Type:

R530

Year Built:

2002

Working Hours:

19000

This used Multivac R530 Thermoformer is built in 2002. On the PLC in the machine is standing 19000 operating hours. The machine has a film width of 420mm and there is a dye set on the machine with an exit of 750mm. The format is now divided in a 3.3 format. The machine is equipped with 5 formats. These formats can be used for Soft Folie packaging. The format does not have a stamp. The frame of the machine is currently 7890mm long, but we can always adjust this to the dimension you need.

Machine details

  • Type under foil unwinding: 76mm Core.
  • Type top foil unwinding: 76mm core.
  • The machine has 6 QRP cuts.
  • The machine is equipped with a Cassette Undercut length cutting.
  • For the process the residual foil is a Roll-up wheels on this machine.
  • The products come from the machine on a Fibre Band.

Other features of the machine
  • Vacum option
  • Gas flushing
  • label option
  • Boosterpump
  • Coarse and fine system

If you wish, you can contact us more photos or information.
